Portable Gantry Crane
Aluminum Gantry Crane
YUANDA A series light duty aluminum gantry cranes are portable, foldable, lightweight, mobile lifting solutions with stable A frame designs. Adjustable height and span.
Span(Width): 3m 4m 5m 6m 8m 10m 12m 15m 10ft 15ft 20ft 25ft foot
Lift Height: 2~12m
Lifting Capacity: 0.25ton 0.5ton 1 2 ton 3 5 7.5 8 10 ton 2000~4000 pounds
Movement mode: Hand push, trackless or travel by motorized wheels
Control method: Pendant wire control or wireless remote control
Working Duty: A3, A4
Ambient Temperature:-20~40℃
Supplier type: China supplier
Aluminum gantry crane price: $4,000~$9,000
Aluminum Gantry Crane
Aluminum Gantry Crane Supplier
Aluminum gantry cranes are an efficient solution for lifting and transporting heavy loads. Their lightweight design makes them easy to handle, while the adjustable height feature allows for precise positioning of the load. With heights varying per model, these adjustable height moveable aluminum gantry cranes provide ample space for moving items around in various industrial, workshop, or garage settings.
Aluminum mobile gantry cranes have a lightweight I-beam that can accommodate height adjustments, single-person lifting of heavier equipment. Configurations can resist corrosion (100 1000 10000 clean grade) and remain unaffected by weather and/or wet conditions, making outdoor use ideal. Corrosion-resistant aluminum gantry cranes have a wide variety of indoor-outdoor, commercial and industrial applications where there is limited space, or when you need an economical way to lift and move heavy loads inside your facility.
Because our foldable portable aluminum gantry cranes are lightweight and easy to transport, assemble, and disassemble, many customers use them for HVAC installation and repair, automotive repair shops, shipyards, scrapyards, construction, warehousing, manufacturing and plant facilities, and municipal maintenance including subways, aviation, buses, boats, machine equipments and building facilities. Other applications include hospitals, universities, airports, aircraft, airplane, the military, clean-room environments, refrigerated areas, and other controlled environments.
PT1 Fixed Height Gantry Crane PT2 Adjustable Height Gantry Crane PT3 Motorized Gantry Crane
LT1 Fixed Height Aluminum Gantry Crane LT2 Adjustable Height LT3 Adjustable Height and Span Crane
LT4 Light Aluminum Gantry Crane LT5 Foldable Aluminum Gantry Crane LT6 Heavy Duty Aluminum Crane
500kg Foldable Aluminum Gantry Cranes Specification & Features
WLL Capacity: 250kg 300kg 500kg 1000kg 1500kg 2000kg 3000kg 5000kg
Loading weight: 500pound, 1000lbs, 2000lbs, 2500lbs, 3000lbs, 4000lbs, 5000lbs,6000lbs,8000lbs
SWL: 0.5t 1t 2t 3t 5t 7.5t 8t 10t
All aluminum alloy construction, 6005 T5 6061 60063 T6, Corrosion-Resistant
Small size, lightweight, light duty, manual hand push to move
Movable on heavy duty durable locking castor wheels with brake
Fast loading unloading
Foldable, adjustable, disassemble, dismantle, knock-down
Complies with CE standards
Height adjustments in 6″ increments
Designed to roll under load
2 Ton Aluminum A Frame Gantry Cranes Options Available
Fixed height or telescopic type height adjustable aluminum gantry crane can be built to order
Adjustable height and span
Height adjustment mode: Height adjusted by manual winch
Electric chain hoist (Motorized or manual chain block)
Manual or electric trolley (Hoist travel)
Electric driven motorized crane travel (Motor rubber wheels)
Site installation available
LT1 1 Ton Fixed Height Aluminum Gantry Crane
LT2 2000kg Telescopic Adjustable Height Aluminum Gantry Crane
LT3 1000 Pounds Adjustable Height and Span Stationary Aluminum Gantry Crane
LT4 250kg Small Portable Disassemble Aluminum Gantry Crane
500kg Foldable Aluminum Gantry Crane
10 Ton Heavy Duty Aluminum Gantry Crane in Workshop
Technical Parameter of Workshop Light Duty Aluminum Gantry Crane
Item | Portable Aluminum Porta Gantry | |||||
Capacity(Ton) | 0.5 ton | 1 ton | 2 ton | 3 ton | 5 ton | 10 ton |
Span(m) | 2-12m (as you require) | |||||
Lifting height(m) | 1-10m (as you require) | |||||
Total height(m) | 1-15m (as you require) | |||||
Wheel | 4 casters | |||||
Lifting equipment | Manual chain block / Electric chain hoist or wire rope hoist | |||||
Power voltage | 380V 50HZ 3P or customized | |||||
Light Weight Aluminum Alloy Gantry Crane Manufacturer in China
YUANDA is a leading China manufacturer of aluminum portal gantry cranes, supplying various of crane and hoist lifting systems to our distributors and directly to end users both in China and overseas. We ship all over the world including the United States, Canada, Indonesia, Singapore, Mexico, Chile, Peru, UAE, Middle East, the United Kingdom, EU, and more. All our mini aluminum gantry cranes are CE certified.
1 ton light duty aluminum gantry crane design drawings can also be provided by our technical team. Contact us now for foldable aluminum gantry crane price.
