3 Ton Jib Crane for Sale

3 Ton Jib Crane Design

Pillar jib crane also called 3 ton pillar mounted jib crane is a type of freestanding small material handling equipment with the base plate installed on the floor without any support attached to the building. It is designed with easy installation and minimal maintenance requirements. Heavy duty 3 ton pillar base plate mounted jib crane is ideal for processes that involve heavy lifting and constant use throughout the day. Fully customizable, this self supporting 360 degree rotating jib crane mounts to the existing floor using high grade anchor bolts. In details, these baseplate-mounted jib cranes have concrete foundations poured around their mast and remain in place stationary and permanently. They provide more stability and loading capacity than 3 ton foundationless jib crane and wall-mounted jib cranes, allowing them to lift heavier loads. 3 Ton fixed jib cranes require preparations and facility constructions like digging holes and pouring concrete foundations. These alterations and investment for 3 ton jib crane installation are important factors to consider before installing a jib crane.

Features of 3 Ton Jib Crane

• Rated lift capacity: 3000kg 3500kg 3ton(tonne/tn/metric ton/MT)

• Heavy loading weight: 6000lbs, 7000lbs, 8000lbs

• SWL/WLL: 3t 3.5t 6000 pounds 8000 pounds

• Crane feature: Heavy duty jib crane

• Swivel angle: 180° 270° 360° degree rotating jib cranes

• Height & Span: 10ft. 12ft. 15ft. 20ft. 25ft. 30ft. 35ft. 25’, 30’, 35’

• Height Under Boom (HUB):5ft 7ft 10ft 12 ft. 15ft. 2 3 4 5 6 8 9 10 m meters

• Overall Height: 5ft 7ft 10ft 13 ft 15ft 20ft 2.5m 3m 4m 5m 6m 8m 9m 10m

• Foundation Width: 2ft 4ft 7ft.

• Crane color: Safety Yellow

• Axial Load: 3 tone

• Hoist & Trolley Allowance: 6000lbs

• Base mounted: Yes

• Base plate thickness at anchor bolt: 1 inch

• Foundation Size: 9’ x 9’ x 4’

• Coverage: 360° circular rotation

• Standards: FEM; ASME B30.20; ASME B30.9; ASME BTH-1

• I beam construction for 3 ton cantilever swing arm jib crane

• Heavy duty gusset & base plate

• Foundations are required for 3 ton free standing jib crane

• Anchored bolts must be set in wet concrete ground

• Festoon cable

• Adjustable collar style rotation stops

• Top entry collector ring & mounting plate

• Control: Pendant control, wire control or wireless radio remote control jib crane

• IP55 IP65 IP56 Protection for motors & panels

• Applicable industries: 3 Ton jib crane for workshops, building material shops, machinery repair shops, manufacturing plant, food & beverage factory, warehouse, construction works, energy & mining, indoor and outdoor.

All YUANDA industrial jib cranes have a design factor of 15% of the allowable capacity for hoist weight and 25% of the allowable capacity for impact.

Heavy Duty 3 Ton Workstation Freestanding Jib Crane for Sale

Heavy Duty 3 Ton Stationary Fixed Floor Mounted Electric Hoist Jib Crane in Workshop

3 Ton Fixed Column Mounted Cantilever Slewing Jib Crane with Electric Hoist

3 Ton 360 Degree Slewing Electric Lifting Pillar Type Cantilever Jib Crane for Sale

3T Jib Crane for Sale

3 Ton Cantilever Wall Mounted Jib Crane with Electric Hoist

3 Ton Motorized Small Mini Mobile Moveable Portable Jib Crane with Wheels

3 Ton Wall Travelling Jib Crane

Different Types of 3 Ton Swing Jib Cranes

3 Ton floor mounted boom lift jib crane is a kind of simple material handling system used for lifting and transporting loads in semi circles or full circles around their support structures. It can cover certain sections of the facility or to be a supplement to an overhead bridge crane. 3 ton column mounted jib crane can be designed in different styles with different characteristics depending on the specific application.

Floor Mounted Jib Crane

This fixed type 3 ton floor mounted jib crane expands the work scope greatly, making the most of the workshop space, having high efficiency in material handling, with 3000 kg lift capacity. The lifting height of the 3 ton post mounted jib crane could be customized as customer's requirements.

Pillar Jib Crane

3 Ton pillar jib crane, also known as column cantilever crane or 3 ton pole mounted jib crane, lifting capacity 3000kg. It features a simple structure, reasonable price, easy operation, and flexible rotating. The column, pole mounted electric hoist slewing jib crane is widely used in factories, workshops production lines, assembly lines, warehouses, docks and other occasions of heavy lifting.

Wall Jib Crane

3 Ton wall mounted jib crane, also known as wall mounted cantilever jib crane, which is installed on walls by brackets. A cantilever wall jib crane has two brackets that attach it to the wall with a cantilever boom. They offer the greatest amount of clearance due to their full cantilever design.

Wall Traveling Jib Crane

3 Ton wall travelling jib crane, also known as wall hanging crane, is developed from the pilaster cantilever crane which is based on a new type of material handling equipment. Wall travelling jib crane traveling rails are installed on the workshop cement column, which could make the longitudinal motion along the crane rails, simultaneously the electric hoist could make lateral movement and vertical lifting along the selected slewing coverage.

Portable Jib Crane with Wheels

3 Ton Portable Jib Cranes, also called mini travelling jib cranes or small mobile movable jib cranes, allow for greater ease of use on the job site without the need for expensive site preparation and footing expenses. As opposed to floor-mounted jib cranes, 3 ton portable jib cranes with wheels are more convenient and cost-effective, allowing for multiple applications in the same environment.

What’s more, 3 ton jib crane for outdoor or specific application, can be designed as hot dip galvanized jib crane, stainless steel jib crane or explosion proof jib crane as special requirements. We can help you to make the right selection of the jib crane for your need. Please leave us a message online now.

Technical Parameters of 3 Ton Jib Crane

*3 ton electric pillar jib crane specifications may be subject to change without notice

3 Ton Jib Crane Accessories, Components and Jib Crane Parts

The heavy duty 3 ton foundation mounted jib crane is engineered as an ergonomic way to raise, lower, and rotate heavy materials for work positioning, transfer, or other operations. Freestanding 360 degree rotating jib crane is designed for floor mounting on a foundation, using high grade anchor bolts and recommended foundation.

3 TON JIB CRANE INCLUDES:

• Column

• I-Beam (Boom)

• Head Assembly

• Jib Crane Slew Motor

• Jib Crane Bearing Cover

• Mast Pillar & Baseplate

• Electric Hoist

• Trolley End Stops

• Festoon System

Hoist Allowance: The total hoist allowance is 15% of the stated capacity. (3 ton workshop jib crane with electric chain hoist)

Boom is made of high grade I Beam or wide flange beam, that conforms to AISC and ASTM standards. Beam girder of the 3 ton I beam jib crane is equipped with removable end stops for quick trolley installation and maintenance. Bearing housing is rigidly mounted on boom.

The mast of the 3 ton workshop jib crane features a heavy pipe design to withstand bending stresses without deflection to boom. Jib crane assembly is jig welded to insure vertical alignment.

Jib crane head is constructed of two heavy reinforcing plates to permit balancing of stress. Top bearing is a tapered roller radial thrust bearing. Lower roller assembly is mounted in a fine processed carriage weldment. Assembly is supported by adjustable tension bolts to permit field adjustment, and to ensure even pressure of the rollers to the pillar. Roller bearings are mounted to the frame through removable steel axles with grease fittings. Electric motor and reducer of the motorized jib crane are all China top brand, or world top brand such as ABB/SEW motor as request. The freestanding heavy duty jib crane is base plate mounted, but is also available as foundation mounted and floor mounted. Hoist brand: Our own brand YUANDA or international top brand such as: Demag, Abus, Kito, KONE, YALE, PLANET, Gorbel, etc.

All structural steel of the 3 ton cantilever jib crane will be painted with safety yellow enamel, this high visibility helps to enhance safety by making the equipment more easily seen by other workers and drivers, reducing the risk of accidents. Other specified color is also available by your requirement.

3 Ton Jib Crane Application

Diverse Applications of 3 Ton Jib Cranes

As a versatile lifting equipment, jib crane plays an important role across diverse industries due to their adaptability and efficiency:

Manufacturing Facilities: 3 Ton industrial jib cranes streamline material handling tasks by lifting heavy machinery, components, and raw materials, optimizing manufacturing processes.

Warehousing: The 3 ton electric hoist jib cranes facilitate swift loading and unloading of goods from trucks and containers, enhancing warehouse logistics and maximizing storage space utilization.

Construction Sites: 3 Ton pedestal slewing jib cranes aid in the vertical and horizontal movement of construction materials, boosting productivity and safety during building projects.

Ports and Docks: These 3 ton marine jib cranes are essential for cargo handling operations, efficiently transferring goods between ships, trucks, and storage areas with precision and speed. They are also called boat crane, dock crane or offshore jib crane. Another type is boat lifting jib crane which is used for lifting boat out of water.

Automotive Industry: 3 Ton workstation jib cranes assist in assembling automobiles by lifting and positioning heavy parts, ensuring smooth production workflows in automotive plants.

Aerospace Sector: The 3 ton fixed floor jib cranes play vital roles in aircraft assembly and maintenance. It can lift and position aircraft components and engines precisely and efficiently.

Maintenance Workshops: 3 Ton swivel jib cranes simplify maintenance works by lifting heavy machinery and components for inspection, repair, and servicing.

Foundries and Forges: These electric jib cranes 3 ton aid in material handling processes, facilitating the movement of molten metal, molds, and heavy castings within foundry operations.

Recycling Facilities: The 3 ton ergonomical jib cranes are instrumental in sorting and transporting recyclable materials, such as metal scraps(usually equipped with magnet lifter) and waste paper, contributing to efficient recycling processes.

Power Generation Plants: 3 Ton swing arm jib cranes assist in power plant operations by handling heavy components and equipment during maintenance, repair, and installation activities.

The 3 ton jib cranes with electric hoist serve as an indispensable machine across various industries, optimizing material handling processes, improving productivity, and ensuring operation safety. Contact us today to learn more about the 3 ton jib crane.

3 Ton Jib Crane Manufacturer in China

As one of the China supplier of industrial jib cranes, we have the most extensive service network in the industry, servicing hundreds of thousands of assets each year of all different loading capacity and models. We have also exported to many countries and regions such as United States, Canada, Indonesia, Mexico, Chile, Peru, Saudi Arabia, Australia, European, UAE, Malaysia, Middle East, the United Kingdom, EU, and more. All our jib cranes are CE certified.

3 ton jib crane drawings, operation manual and jib crane design calculation can also be provided by our technical team. Contact us now for 3 ton jib crane price.
